Machine description – quick overview
Description
0
Key button, automatic cutout
Wire feed motor supply voltage fuse
press to reset a triggered fuse
G¼" connection thread, shielding gas connection, inlet
Cooling air outlet
Mains connection cable
- See 5.6 Mains connection chapter
5-pole connection socket
Cooling unit voltage supply
Intermediate hose package strain relief
Machine feet
Rear view
