Design and function
Interfaces

5.21.4 Connecting the WELDQAS welding data monitoring and documentation system

Network-compatible welding data monitoring and documentation system for digital power sources.
Item Symbol
1
2
3
4
5
6
64
Description 0
7-pole connection socket (digital)
For connecting digital accessory components
Windows PC
WELDQAS welding data monitoring and documentation system
7-pole connection cable
Connection between switching cabinet and power source
Integration option of WELDQAS into existing network systems via network
cables
Connection cable included as standard with WELDQAS
Figure 5-26
