5.14.6 Connecting the WELDQAS welding data monitoring and documentation system

Network-compatible welding data monitoring and documentation system for digital power sources.
Item Symbol
1
2
3
4
5
6
099-005366-EW501
31.07.2014
Description 0
7-pole connection socket (digital)
For connecting digital accessory components
Windows PC
WELDQAS welding data monitoring and documentation system
Connection cable, 7-pole
Connection between switching cabinet and power source
Integration option of WELDQAS into existing network systems via network
cables
Connection cable included as standard with WELDQAS
Design and function
Figure 5-14
Interfaces
