Function:
®
The 2N Security Relay
area) and the electric lock (inside the secured area). The
relay that can only be activated if the valid opening code is received from the
intercom.
Specifications:
Passive switch: NO and NC contacts, up to 30 V / 1 A AC/DC
Switched output:
Where the security relay is fed from the intercom, 9 to 13 V DC is available on
the output depending on the power supply (PoE: 9 V; adapter: source voltage of
minus 1 V) / 400 mA DC.
Where the security relay is fed from an external power supply, 12 V / 700 mA DC
is available on the output.
Dimensions: (56 x 31 x 24) mm
Weight: 20 g
Installation:
®
Install the 2N Security Relay
electric lock inside the area to be secured (typically behind the door). The device is
powered and controlled via this two-wire cable and so can be added to an existing
installation. Thanks to its compact dimensions, the device can be installed into a
standard mounting box.
Connection:
®
Connect the 2N Security Relay
To the intercom active output (OUT1 or OUT2) , or
To the intercom relay output with a 12 V DC serial external power supply.
Connect the electric lock to the
To the switched output.
To the passive output in series with the external power supply.
2N TELEKOMUNIKACE a.s., www.2n.cz
is a device installed between an intercom (outside the secured
onto a two-wire cable between the intercom and the
to the intercom as follows:
®
2N Security Relay
®
2N Security Relay
output as follows:
includes a
