  • Page 1 2N IP One User Manual...

  • Page 2: Table Of Contents

    IP address ..........................30 Web Configuration Interface Login ....................30 IP Address Retrieval ........................31 IP Address Retrieval Using 2N Network Scanner ................. 31 Dynamic/Static IP Address Switching ..................... 32 Device Restart ..........................32 Restart Using Web Configuration Interface, ................. 33 Firmware Update ..........................

  • Page 3: Symbols And Terms Used

    Symbols and Terms Used Symbols and Terms Used The following symbols and pictograms are used in the manual: DANGER Always abide by this information to prevent persons from injury. WARNING Always abide by this information to prevent damage to the device. CAUTION Important information for system functionality.

  • Page 4: Product Description

    Product Description Product Description In this section, we introduce the 2N IP One product, outline its application options and highlight the advan- tages following from its use. Basic Features 2N IP One is an elegant yet robust and mechanically resistant IP video intercom designed for residential buildings.

  • Page 5: Product Versions

    2N IP One Main Unit – Bronze Accessories Accessories for Installation 2N IP One is designed for outdoor applications and requires no additional roof. Choose the proper a mounting box depending on your particular installation needs. Part No. 9158001 Axis Part No. 02941-001...
  • Page 6 Product Description Part No. 9159010 Axis Part No. 01386-001 Security Relay A handy add-on that significantly enhances security. It prevents lock tampering. To be installed between the protected device from which it is also powered and the lock controlled by it.

  • Page 7: Electric Locks

    Product Description Electric Locks Part No. 11202101 Electric opener Mini 5 series – short The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Features: • short sheet metal front cover version (130 mm) •...
  • Page 8 Product Description Part No. 11202103 Electric opener Mini 5 series with mechanical blocking – short The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Features: Part No. 11202103-L Electric opener Mini 5 series with mechanical blocking – long The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Features:...
  • Page 9 Product Description Part No. 11202105 Electric fail safe opener Mini 5 series with mechanical blocking – short The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Under voltage, the opener is secured, i.e. blocked, once voltage is stopped, the opener is unblocked and the door can be opened.
  • Page 10 The self-locking 72/55 lock with panic function is a suitable solution for emergency exits. A key is necessary to open the door from the outside (or an electric pulse from a connected 2N IP intercom/reader). Part No. 11202201-M Electromechanical lock SAM 7255 with monitoring The self-locking 72/55 lock with panic function is a suitable solution for emergency exits.
  • Page 11 Product Description Part No. 11202302 Cable bushing FX510 Provides secure passage and protection of the power cable between the door frame and the door wing. Features: • 510 mm length Part No. 11202303 Cable protector FX300G Provides secure passage and protection of the power cable between the door frame and the door wing.
  • Page 12 Interconnectable with a motion sensor and electronic access control system. Can be used both for the right and left doors and is available in the IN/OUT opening design. FAQ: Electric locks – Differences between locks for 2N IP access systems...

  • Page 13: Power Supply

    Designed for external supply of electric locks. Part No. 9159052 Axis Part No. 01393-001 12 V / 1 A power supply for 2N Induction Loop The external induction loop power supply has 230 V AC input voltage and 12 V DC output voltage.

  • Page 14: Other Accessories

    Product Description Other accessories...
  • Page 15 Product Description Part No. 9159013 Axis Part No. 02523-001 Departure button The departure button is connected to the device logic input for opening the door from inside the building. Part No. 9159012 Axis Part No. 01388-001 Magnetic door contact Set for installation on a door, enabling the status of door opening to be ascertained.
  • Page 16 Product Description Part No. 9134166E Axis Part No. 01396-001 RFID chip fob EM, 125 Hz RFID chip fob, type EM4100, 125 kHz. Part No. 11202601 Axis Part No. 02787-001 RFID chip card MIFARE DESFire, 13.56 MHz RFID chip fob, type MIFARE DESFire EV3 4 K, 13.56 MHz (ISO/ IEC14443A).
  • Page 17 • FeliCa (Standard, Lite) • ST SR (SR, SRI, SRIX) • Mobile Key The device can also read the 13.56 MHz 2N PICard RFID cards. Part No. 9137424E Axis Part No. 01527-001 External secured RFID reader, 13.56 MHz + 125 kHz, NFC/HCE External secured RFID card reader connectable to a PC via a USB interface.
  • Page 18 IP de- vice. You do not have to configure anything, all you need is one 2N 2Wire unit at each end of the cable and a power supply connected to at least one of these units.

  • Page 19: Package Completeness Check

    Torx head screw Torx wrench Component Layout 2N IP One is equipped with the following buttons on its backside: Tamper Switch The purpose of the tamper switch is to signal any unauthorized opening of the intercom (to prevent a theft, e.g.).

  • Page 20: Installation

    If the difference is too great, separate the device in terms of pressure (using, e.g., a mounting box) and seal the cable passage. Flush mounting The flush mounting box allows you to place cables in the wall below 2N IP One and mount the device.
  • Page 21 Installation What you need for mounting: • 2N IP One • Flush mounting box (Part No. 9158001) WARNING Before starting the mechanical installation on a selected place, make sure carefully that the preparations associated with it (drilling, wall cutting) cannot damage the electrical, gas,...
  • Page 22 Installation...

  • Page 23: Electric Installation

    Loosen the screw if too tight to make the device fit in the box. Then tighten the screw again. Electric Installation Power Supply 2N IP One can be fed either directly from the LAN if equipped with PoE 802.3af supporting network elements or from an external 12 V ±15 % / 2 A DC power supply.
  • Page 24 Current consumption [A] Available power output [W] Combined Power Supply 2N IP Onecan be fed from an external power supply and PoE at the same time. In this configuration, the maximum power for the is available.

  • Page 25: Device Connectors

    LAN Connection 2N IP One is connected to the LAN by inserting a SSTP cable (category Cat-5e or higher) in the dedicated LAN connector on the device. As the device is equipped with the Auto-MDIX function, you can use either the...

  • Page 26: Overvoltage Protection

    • We recommend the use of a shielded SSTP Ethernet cable. Overvoltage Protection The 2N device cables have to be protected against atmospheric overvoltage caused by external causes (lightning, e.g.). A surge can damage a device installed outside/inside the building if the wires are unprotec- ted.
  • Page 27 Installation Examples of Overvoltage Protection Installation Figure 2. Overvoltage protection installation diagram for a device installed on the building facade and cables outside the building...
  • Page 28 Installation Figure 3. Overvoltage protection installation diagram for a device installed on the building facade and cables inside the building...

  • Page 29: Installation Completion

    Installation Figure 4. Overvoltage protection installation diagram for a device and cables installed outside the building Installation Completion Check the connection of all the wires in the board connector. WARNING • Make sure that all the terminals of the unused connectors are properly tightened to avoid vibrations caused by sound.

  • Page 30: Brief Guidelines

    Call Connection (p. 33) Device Configuration Interface Access 2N IP One is configured via the administration web interface. Connect the device to the LAN IP and make sure it is properly powered. You have to know the IP address for access.

  • Page 31: Ip Address Retrieval

    • Use the freely accessible 2N Network Scanner. • Use the Speed Dial button. IP Address Retrieval Using 2N Network Scanner The application helps you find the IP addresses of all the 2N devices in the LAN. Download 2N Network Scanner from the 2N.com website.

  • Page 32: Dynamic/Static Ip Address Switching

    Select the device to be configured and right-click it. SelectBrowse... to open the device administration web interface login box for configuration. • Double click the selected row in the 2N Network Scanner list to access the device web interface easily.

  • Page 33: Restart Using Web Configuration Interface

    Restart the device in System > Maintenance > System using Restart . Firmware Update We recommend that the firmware is also updated during the 2N IP One installation. Refer to 2N.com for the latest FW version. Update firmware via the web configuration interface in System > Maintenance, refer to the device Configura- tion Manual.
  • Page 34 Buttons, refer to Buttons. Make sure that the call transmitting service is enabled on the called 2N device to make a successful call. • Each user can be assigned up to 3 phone numbers. In case the first user fails to answer, the call is forwarded to the next number.

  • Page 35: Device Control

    • closing a switch (e.g. opening a door, operating an elevator, etc.) by entering a numeric access code on the application keyboard 2N Mobile Key • device control using a touch screen • activate and deactivate users or profiles using the mobile application 2N Mobile Key...

  • Page 36: Troubleshooting

    Troubleshooting Troubleshooting Refer to faq.2n.cz for the most frequently solved problems.

  • Page 37: Technical Parameters

    Technical Parameters Technical Parameters Power Supply Types IEEE 802.3af, Class 0 (0.44–12,95 W, 44-57 V DC, 400 mA) External supply 12 V ±15 % / 2 A DC Signaling protocol UDP, TCP, TLS Audio Microphone Elektretový Amplifier 3 W RMS / 6 W (třída D) Speaker 3 W / 4 Ω...
  • Page 38 Technical Parameters Audio stream Protocols • RTP • RTSP Codecs and Used Bandwidth • G.711 (PCMA, PCMU) – 64 kbps (with 85.6 kbps headers) • G.729 – 16 kbps (with 29.6 kbps headers) • G.722 – 64 (with 85.6 kbps headers) •...
  • Page 39 Technical Parameters Video stream Protocols • RTP • RTSP • SRTP • HTTP ONVIF/RTSP streaming codecs • H.264, MJPEG • H.265 • MJPEG IP Camera Function Yes – compatible profiles: • ONVIF v2.4 profile S Interface 10/100BASE-TX s Auto-MDIX, RJ-45 Recommended cabling Cat-5e or higher Switched voltage...
  • Page 40 Technical Parameters Mechanical Parameters Cover Hardened glass Body material • Black version: • Material - Zamak 410 - Zn95Al4Cu1 • Surface treatment – PUR Wet coating 15-25 μm, RAL 9005 Jet black, inner side - passivated zinc Body material • Material – EN AC-46100 •...

  • Page 41: Directives, Laws And Regulations - General Instructions And Cautions

    Directives, Laws and Regulations - General Instructions and Cautions Directives, Laws and Regulations - General Instructions and Cautions 2N IP One conforms to the following directives and regulations: • 2014/30/EU for electromagnetic compatibility • 2014/53/EU for radio equipment • 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment •...
  • Page 42 / devices of other suppliers, the customer agrees that the 2N TELEKOMUNIKACE a.s. company shall not be held liable for any functionality limitation of such a product or any damage, loss or injury related to this potential functionali- ty limitation.
  • Page 43 Directives, Laws and Regulations - General Instructions and Cautions All applicable legal regulations concerning the product installation and use as well as provisions of technical standards on electric installations have to be obeyed. The manufacturer shall not be liable and responsible for damage or destruction of the product or damage incurred by the consumer in case the product is used and handled contrary to the said regulations and provisions.
  • Page 44 2N IP One – User Manual © 2N Telekomunikace a. s., 2024 2N.com...
