Camera

Through the MB1262/CN7 connector, a camera module mounted on a daughterboard MB1379 is provided.
MB1379 is a 5 Mpixels, 8-bit color camera module based on OV5640 image sensor, clocked from a 24 MHz
crystal (MB1379/X1). It is supplied by 2V8.
6.17.1

Camera interface

MB1379 is connected to the STM32MP157xAA3 through DCMI and I
are connected to MFX.
The I2C is I2C2 that is shared with all the peripherals: audio codec, MFX, RGB LTDC, DSI LCD, and USB hub.
The camera I²C address is 0x3C.
Table 24 describes the IO configuration for the camera interface.
IO
PH4
PH5
PH9
PH10
PH11
PH12
PH14
PI4
PB8
PE6
PI1
PH7
PI3
PH15
PB7
PH8
PA6
MFX_IO12
