JOY_RIGHT: Joystick right direction (MB1262/B1 pin6)
JOY_UP: Joystick up direction (MB1262/B1 pin4)
6.6
Boot options
The STM32MP157x-EV1 board may boot from different sources as described in
Boot Mode
Serial-NOR
uSD card
eMMC
NAND
UART and USB
Reserved
The boot related switches (MB1263/SW1) must be configured as illustrated by one of the following pictures:
UM2535 - Rev 1
Devices
Table 9.
HW configuration for the BOOT mode MB1263/SW1
BOOT2
0
1
0
0
0
1
1
Purpose/IO
MFX_IO3
MFX_IO4
Table
BOOT1
0
0
1
1
0
1
0
UM2535
Boot options
9.
BOOT0
1
1
0
1
0
0
0
page 14/55
