B Appendix B STM32MP157x-EV1 IO Assignment
LFBGA448 ball
AA3
V4
AB2
T4
V6
U5
W9
Y9
B13
A11
Y17
Y16
W16
W3
R3
E11
AB5
AA5
V13
A12
C13
AA8
W13
F11
AB8
F12
V9
Y5
AA7
V10
A13
B12
U10
AB3
Y1
U3
AB6
UM2535 - Rev 1
Table 47. STM32MP157x-EV1 IO Assignment
IO Port Main function
PA0 WAKE_UP
PA1 ETH_RX_CLK
PA2 ETH_MDIO
PA3 TIM2_CH4
PA4 ADC1_IN18_DACOUT1
PA5 ADC1_IN19_DACOUT2
PA6 DCMI_PIXCLK
PA7 ETH_RX_DV
PA8 SDMMC2_D4
PA9 SDMMC2_D5
PA10 OTG_ID
PA11 I2C5_SCL
PA12 I2C5_SDA
PA13 PA13 GPIO
PA14 PA14 GPIO
PA15 HDMI_CEC
PB0 ETH_RXD2
PB1 ETH_RXD3
PB2 UART4_RX
PB3 SDMMC2_D2
PB4 SDMMC2_D3
PB5 SPDIF_TX
PB6 QSPI_BK1_NCS
PB7 DCMI_VSYNC
PB8 DCMI_D6
PB9 SDMMC1_CDIR
PB10 USART3_TX
PB11 ETH_TX_EN
PB12 USART3_RX
PB13 DFSDM_CKOUT
PB14 SDMMC2_D0
PB15 SDMMC2_D1
PC0 QSPI_BK2_NCS
PC1 ETH_MDC
PC2 ETH_TXD2
PC3 DFSDM_DATA1
PC4 ETH_RXD0
Appendix B STM32MP157x-EV1 IO Assignment
Motor Control connector
Bus Voltage
Emergency Stop
PFC PWM
UM2535
page 44/55
