Libelium Waspmote Technical Manual page 92

Protocol: LoRaWAN 1.0, Class A
LoRaWAN-ready
Frequency:
LoRaWAN EU module: 868 MHz and 433 MHz ISM bands
•
LoRaWAN US module: 902-928 MHz ISM band
•
LoRaWAN AU module: 915-928 MHz ISM band
•
LoRaWAN IN module: 865-867 MHz ISM band
•
LoRaWAN ASIA-PAC / LATAM module: 923 MHz ISM band
•
TX power:
LoRaWAN EU module: up to 14 dBm
•
LoRaWAN US module: up to 18.5 dBm
•
LoRaWAN AU module: up to 18.5 dBm
•
LoRaWAN IN module: up to 18.5 dBm
•
LoRaWAN ASIA-PAC / LATAM module: up to 18.5 dBm
•
Sensitivity: down to -136 dBm
Range: >15 km at suburban and >5 km at urban area. Typically, each base station covers some km. Check the
LoRaWAN Network in your area.
Chipset consumption:
LoRaWAN EU module: 38.9 mA
•
LoRaWAN US module: 124.4 mA
•
LoRaWAN AU module: 124.4 mA
•
LoRaWAN IN module: 124.4 mA
•
LoRaWAN ASIA-PAC / LATAM module: 124.4 mA
•
Radio data rate:
LoRaWAN EU module: from 250 to 5470 bps
•
LoRaWAN US module: from 250 to 12500 bps
•
LoRaWAN AU module: from 250 to 12500 bps
•
LoRaWAN IN module: from 250 to 12500 bps
•
LoRaWAN ASIA-PAC / LATAM module: from 250 to 12500 bps
•
Receiver: purchase your own base station or use networks from LoRaWAN operators
Related API libraries: WaspLoRaWAN.h, WaspLoRaWAN.cpp
All the information about their programming and operation can be found in the
available at Development section of Libelium website.
-92-
LoRaWAN modules
Figure: LoRaWAN EU module
