TX power:
Europe/Brazil:
Class 4 (2 W, 33 dBm) @ GSM 900
-
Class 1 (1 W, 30 dBm) @ GSM 1800
-
Class E2 (0.5 W, 27 dBm) @ EDGE 900
-
Class E2 (0.4 W, 26 dBm) @ EDGE 1800
-
Class 3 (0.25 W, 24 dBm) @ UMTS
-
Class 3 (0.2 W, 23 dBm) @ LTE
-
America:
Class 4 (2 W, 33 dBm) @ GSM 900
-
Class 1 (1 W, 30 dBm) @ GSM 1800
-
Class E2 (0.5 W, 27 dBm) @ EDGE 900
-
Class E2 (0.4 W, 26 dBm) @ EDGE 1800
-
Class 3 (0.25 W, 24 dBm) @ UMTS
-
Class 3 (0.2 W, 23 dBm) @ LTE
-
Australia:
Class 3(0.2W, 23 dBm) @ LTE
-
Antenna connector:
U.FL for main antenna
U.FL for cellular diversity antenna
U.FL for GPS antenna (only for Europe/Brazil and America modules)
External antenna: +5 dBi
GPS: GPS feature is supported only in Europe/Brazil and America versions
This module can carry out the following tasks:
Sending/Receiving SMS
Multisocket up to 6 TCP/IP and UDP/IP clients
TCP/IP server
TCP SSL
HTTP service
FTP service (downloading and uploading files)
Sending/receiving email (SMTP/POP3)
Certifications:
LE910-EUG (Europe / Brazil): CE, GCF, ANATEL
LE910-NAG (US / Canada): FCC, IC, PTCRB, AT&T approved
LE910-AU V2 (Australia): RCM, Telstra approved
LE910-SKG (South Korea): KCC, SK Telecom approved
LE910-JN V2 / LE910-JK V2 (Japan): NTT DoCoMo, KDDi
This model uses the UART1 at a baudrate of 115200 bps to communicate with the microcontroller.
Related API libraries: Wasp4G.h, Wasp4G.cpp
All information about programming and operation can be found in the
All the documentation is located in the
Note: A rechargeable battery must be always connected when using this module (USB power supply is not enough).
Development section
of Libelium website.
-104-
4G Networking
Guide.
4G module
v8.2
