Sensor sockets are configured as shown in the figure below.
Sensor
Socket
Parameter
Weather Station WS-3000 (anemometer + wind vane +
A
pluviometer)
B Soil Moisture 1
C Soil Moisture 3
Soil Temperature
Temperature + Humidity + Pressure
D
Luminosity (Luxes accuracy)
Ultrasound (distance measurement)
Leaf Wetness
E
Soil Moisture 2
Temperature + Humidity + Pressure
F (digital
Luminosity (Luxes accuracy)
bus)
Ultrasound (distance measurement)
Figure: Sensor sockets configuration for Smart Agriculture model
Note: For more technical information about each sensor probe go to the
website.
Sensor probes allowed for each sensor socket
-45-
Reference
9256-P
9248-P, 9324-P, 9323-P
9248-P, 9324-P, 9323-P
86949-P
9370-P
9325-P
9246-P
9249-P
9248-P, 9324-P, 9323-P
9370-P
9325-P
9246-P
