Sensor sockets are configured as shown in the figure below.
Sensor
A, B, C, D and E
A and D
F
Figure: Sensor sockets configuration for Smart Water Xtreme model
Note: For more technical information about each sensor probe go to the
website.
Sensor probes allowed for each sensor socket
Parameter
Optical dissolved oxygen and temperature
OPTOD
Titanium optical dissolved oxygen and
temperature OPTOD
pH, ORP and temperature PHEHT
Conductivity, salinity and temperature C4E
Inductive conductivity,
temperature CTZN
Turbidity and temperature NTU
Suspended solids, turbidity, sludge blanket
and temperature MES5
Temperature, air humidity and pressure
Luxes
Ultrasound
Manta+40
Chlorophyll
BGA
Organic matter CDOM/FDOM
Ammonium
Nitrate
Chloride
Sodium
Calcium
Reference
9488-P
9489-P
9485-P
9486-P
salinity and
9487-P
9353-P
9490-P
9370-P
9325-P
9246-P
9495-P
72470
72471
72472
72473
72474
72475
72476
72477
