9. 802.15.4/ZigBee/RF modules

Waspmote integrates the Digi's XBee modules for communication in the ISM (Industrial Scientific Medical) bands.
These modules communicate with the microcontroller using the UART0 or UART1 at 115200 bps.
There are several possible XBee modules distributed by Libelium for integration in Waspmote.
Radio version
XBee-PRO 802.15.4 EU
XBee-PRO 802.15.4
XBee-PRO DigiMesh
XBee-PRO ZigBee
XBee 868LP
XBee 900HP US
XBee 900HP BR
XBee 900HP AU
* To determine your range, perform a range test under your operating conditions
Frequency Transmission power
2.4 GHz
2.4 GHz
2.4 GHz
2.4 GHz
863 - 870 MHz
902 - 928 MHz
902 - 906.8 MHz
915.6 - 928 MHz
915.6 - 928 MHz
Sensitivity
10 dBm -100 dBm
18 dBm -100 dBm
18 dBm -100 dBm
17 dBm -102 dBm
14 dBm -106 dBm
24 dBm -110 dBm
24 dBm -110 dBm
24 dBm -110 dBm
-83-
802.15.4/ZigBee/RF modules
Range*
750 m
1600 m
1500 m
3200 m
8.4 km
15.5 km
15.5 km
15.5 km
