Single
This variant includes a Single Junction Reference Probe, so it can read all the single type ion sensors.
Sensor sockets are configured as shown in the table below.
Sensor
Socket
A, B, C and D
E
F
Figure: Sensor sockets configuration for Smart Water Ions model, single variant
Note: For more technical information about each sensor probe go to the
website.
Double
This variant includes a Double Junction Reference Probe, so it can read all the double type ion sensors.
Sensor sockets are configured as shown in the table below.
Sensor
Socket
A, B, C and D
E
F
Figure: Sensor sockets configuration for Smart Water Ions model, double variant
Note: For more technical information about each sensor probe go to the
website.
Sensor probes allowed for each sensor socket
Parameter
Fluoride Ion (F )
-
Fluoroborate Ion (BF4 )
-
Nitrate Ion (NO )
-
3
pH (for Smart Water Ions)
Single Junction Reference
Soil/Water Temperature
Sensor probes allowed for each sensor socket
Parameter
Bromide Ion (Br )
-
Chloride Ion (Cl )
-
Cupric Ion (Cu )
2+
Iodide Ion (I )
-
Silver Ion (Ag )
+
pH (for Smart Water Ions)
Double Junction Reference
Soil/Water Temperature
-41-
Reference
9353
9354
9355
9363
9350 (included by default)
9255-P (included by default)
Development section on the Libelium
Reference
9356
9357
9358
9360
9362
9363
9351 (included by default)
9255-P (included by default)
Development section on the Libelium
Waspmote Kit
