Xbee 868Lp - Libelium Waspmote Technical Manual

802.15.4/ZigBee/RF modules
Figure: Tree topology
Regarding the transmission power, it cannot be adjusted because it is always set to 17 dBm.
Related API libraries: WaspXBeeCore.h, WaspXBeeCore.cpp, WaspXBeeZB.h, WaspXBeeZB.cpp
All information about their programming and operation can be found in the ZigBee Networking Guide.
All the documentation is located in the Development section in the Libelium website.

9.3. XBee 868LP

Radio Frequency Transmission power Sensitivity Range*
version
XBee 868LP 863 - 870 MHz 14 dBm -106 dBm 8.4 km
* To determine your range, perform a range test under your operating conditions
Figure: XBee 868LP
Note: The XBee 868 MHz module is provided with 4.5dBi antenna, which enables maximum range.
-87- v8.2
