Note: Waspmote must not be switched off or reseted while there are ongoing read or write operations in the SD card.
Otherwise, the SD card could be damaged and data could be lost.

27. Energy Consumption

27.1. Consumption tables

Waspmote
On
Sleep
Deep Sleep
Hibernate
XBee
XBee-PRO 802.15.4
XBee-PRO ZigBee
XBee 868LP
XBee-PRO 900HP
Bluetooth modules
Bluetooth Pro
Bluetooth Low
Energy
GPS
On (tracking)
Off (Waspmote switch)
GPRS Pro
Connecting ~100 mA
Calling ~100 mA
Receiving calls ~100 mA
Transmitting GPRS ~100 mA
Sleep 1 mA
Off ~0 μA
17 mA
30 μA
33 μA
7 μA
SENDING RECEIVING
250 mA 55 mA
295 mA 45 mA
48 mA 27 mA
215 mA 29 mA
On Off
14 mA 0 mA
8 mA 0 mA
32 mA
0 μA
Sleep Scanning
<0,5 mA 40 mA
0.4 μA 36 mA
-122-
Energy Consumption
Sending Receiving
34 mA 20 mA
36 mA 36 mA
