Sensor sockets are configured as shown in the figure below.
Sensor
Socket
A
B
C
E
F
Figure: Sensor sockets configuration for Smart Water model
Note: For more technical information about each sensor probe go to the
website.
Sensor probes allowed for each sensor socket
Parameter
pH
Dissolved Oxygen (DO)
Conductivity
Oxidation-Reduction Potential (ORP)
Soil/Water Temperature
Turbidity
Reference
9328
9327
9326
9329
9255-P (included by default)
9353-P
