9.1. XBee-PRO 802.15.4

Radio version
XBee-PRO 802.15.4 EU
XBee-PRO 802.15.4
* To determine your range, perform a range test under your operating conditions
Figure: XBee-PRO 802.15.4
The frequency used is the free band of 2.4 GHz, using 12 channels with a bandwidth of 5 MHz per channel.
Figure: Frequency channels in the 2.4 GHz band
Transmission
Frequency
10 dBm
2.4 GHz
18 dBm
Channel Number
0x0C – Channel 12
0x0D – Channel 13
0x0E – Channel 14
0x0F – Channel 15
0x10 – Channel 16
0x11 – Channel 17
0x12 – Channel 18
0x13 – Channel 19
0x14 – Channel 20
0x15 – Channel 21
0x16 – Channel 22
0x17 – Channel 23
Sensitivity
power
-100 dBm
Frequency
2.405 – 2.410 GHz
2.410 – 2.415 GHz
2.415 – 2.420 GHz
2.420 – 2.425 GHz
2.425 – 2.430 GHz
2.430 – 2.435 GHz
2.435 – 2.440 GHz
2.440 – 2.445 GHz
2.445 – 2.450 GHz
2.450 – 2.455 GHz
2.455 – 2.460 GHz
2.460 – 2.465 GHz
-84-
802.15.4/ZigBee/RF modules
Range*
750 m
1600 m
