Libelium Waspmote Technical Manual page 88

The frequency used is the 868 MHz band, using 30 software selectable channels. Channels are spaced 100 kHz
apart. The transmission rate is 10 kbps.
The classic topology for this type of network is a star topology, as the nodes can establish point-to-point
connections with brother nodes through the use of the MAC address.
Figure: Star topology
Regarding the transmission power, it can be adjusted to several values:
Figure: Transmission power values
Related API libraries: WaspXBeeCore.h, WaspXBeeCore.cpp, WaspXBee868LP.h, WaspXBee868LP.cpp
All information about their programming and operation can be found in the
All the documentation is located in the
Parameter XBee 868LP
0 3 dBm
1 7 dBm
2 10 dBm
3 12 dBm
4 14 dBm
Development section in the Libelium website.
-88-
802.15.4/ZigBee/RF modules
868 Networking Guide.
