Pin
Signal Name
Number
L39 QSFP1_RX2_N
L38 QSFP1_RX2_P
J39 QSFP1_RX3_N
J38 QSFP1_RX3_P
D30 QSFP1_SEL_1V8_L
P36 QSFP1_TX0_N
P35 QSFP1_TX0_P
M36 QSFP1_TX1_N
M35 QSFP1_TX1_P
K36 QSFP1_TX2_N
K35 QSFP1_TX2_P
H36 QSFP1_TX3_N
H35 QSFP1_TX3_P
R6 REFCLK100_PIN_N
R7 REFCLK100_PIN_P
L30 SI5328_1V8_SCL
L29 SI5328_1V8_SDA
M30 SI5328_REFCLK_IN_N
M29 SI5328_REFCLK_IN_P
L34 SI5328_REFCLK_OUT0_PIN_N
L33 SI5328_REFCLK_OUT0_PIN_P
R34 SI5328_REFCLK_OUT1_PIN_N
R33 SI5328_REFCLK_OUT1_PIN_P
AT25 SPARE_SCL
AT26 SPARE_SDA
AP23 SPARE_WP
AW24 SRVC_MD_L_1V8
Y10
AC9
Y9
AD10
AT27 USER_LED_G0
AU27 USER_LED_G1
AU23 USER_LED_R
AV27 USR_SW0
Table 15 : Complete Pinout Table (continued on next page)
TCK
TDI
TDO
TMS
ADM-PCIE-9V3 User Manual
Bank Voltage
MGT
MGT
MGT
MGT
1.8
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT
1.8
1.8
1.8 (LVDS)
1.8(LVDS)
MGT_REFCLK
MGT_REFCLK
MGT_REFCLK
MGT_REFCLK
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
Complete Pinout Table
