ADM-PCIE-9V3 User Manual
Complete Pinout Table
ad-ug-1322_v2_7.pdf
Pin
Signal Name
Number
L18 DDR4_0_DQ57
N19 DDR4_0_DQ58
M21 DDR4_0_DQ59
M11 DDR4_0_DQ6
M19 DDR4_0_DQ60
M22 DDR4_0_DQ61
L19 DDR4_0_DQ62
M20 DDR4_0_DQ63
H16 DDR4_0_DQ64
K15 DDR4_0_DQ65
J16 DDR4_0_DQ66
J14 DDR4_0_DQ67
K13 DDR4_0_DQ68
L13 DDR4_0_DQ69
K10 DDR4_0_DQ7
H14 DDR4_0_DQ70
J15 DDR4_0_DQ71
L17 DDR4_0_DQ8
M16 DDR4_0_DQ9
L12 DDR4_0_DQS0_C
M12 DDR4_0_DQS0_T
L14 DDR4_0_DQS1_C
L15 DDR4_0_DQS1_T
E13 DDR4_0_DQS2_C
F13 DDR4_0_DQS2_T
A15 DDR4_0_DQS3_C
B15 DDR4_0_DQS3_T
E22 DDR4_0_DQS4_C
F22 DDR4_0_DQS4_T
B21 DDR4_0_DQS5_C
C21 DDR4_0_DQS5_T
K20 DDR4_0_DQS6_C
K21 DDR4_0_DQS6_T
K22 DDR4_0_DQS7_C
L22 DDR4_0_DQS7_T
Table 15 : Complete Pinout Table (continued on next page)
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
