3.7 System Monitor

The ADM-PCIE-9V3 has the ability to monitor temperature, voltage, and current of the system to check on the
operation of the board. The monitoring is implemented using an Atmel AVR microcontroller.
If the core FPGA temperature exceeds 100 degrees Celsius, the FPGA will be cleared to prevent damage to the
card.
Control algorithms within the microcontroller automatically check line voltages and on board temperatures and
shares makes the information available to the FPGA over a dedicated serial interface built into the Alpha Data
reference design package (sold separately). The information can also be accessed directly from the
microcontroller over the USB interface on the front panel or via the IPMI interface available at the PCIe card
edge.
Monitors
ETC
EC
12.0V
3.3V
3.3V
3.3V
2.5V
1.8V
1.8V
1.2V
1.2V
0.9V
0.85V
0.6V
12V_I
3.3V_I
1.8V_MGT_I
2.5V_DIG_I
uC_Temp
Board0_Temp
Board1_Temp
FPGA_Temp
Page 14
Index Purpose/Description
ETC Elapsed time counter (seconds)
EC Event counter (power cycles)
ADC00 Board Input Supply
ADC01 Board Input Supply
ADC02 Board Input Auxilary Power Supply
PSU0OK Internal logic voltage
ADC03 Clock and DRAM Voltage Supply
PSU0OK FPGA IO Voltage (VCCO)
ADC04 Transceiver Power (AVCC_AUX)
ADC05 DDR4 SDRAM and FPGA memory I/O
ADC06 Transceiver Power (AVTT)
ADC07 Transceiver Power (AVCC)
ADC08 FPGA Core Supply (VccINT)
ADC09 DDR4 Termination Voltage
ADC10 12V input current in amps
ADC11 3.3V input current in amps
ADC12 1.8V MGT supply current in amps
ADC13 2.5V supply current in amps
TMP00 FPGA on-die temperature
TMP01 Board temperature near front panel
TMP02 Board temperature near back top corner
TMP03 FPGA on-die temperature
Table 13 : Voltage, Current, and Temperature Monitors
