3.7.1 System Monitor Status LEDs

LEDs D6 (Red) and D5 (Green) indicate the card health status.
Functional Description
ad-ug-1322_v2_7.pdf
LEDs
Green
Green + Red
Flashing Green + Flashing Red
(together)
Flashing Green + Flashing Red
(alternating)
Flashing Green + Red
Red
Flashing Red
Table 14 : Status LED Definitions
Status
Running and no alarms
Standby (Powered off)
Attention - critical alarm active
Service Mode
Attention - alarm active
Missing application firmware or
invalid firmware
FPGA configuration cleared to
protect board
Page 15
