Alpha Data ADM-PCIE-9V3 User Manual page 33

ADM-PCIE-9V3 User Manual
Complete Pinout Table
ad-ug-1322_v2_7.pdf
Pin
Signal Name
Number
AN19 DDR4_1_DQ62
AL20 DDR4_1_DQ63
AF15 DDR4_1_DQ64
AJ17 DDR4_1_DQ65
AH17 DDR4_1_DQ66
AJ14 DDR4_1_DQ67
AG15 DDR4_1_DQ68
AJ13 DDR4_1_DQ69
AJ12 DDR4_1_DQ7
AG17 DDR4_1_DQ70
AJ16 DDR4_1_DQ71
AM15 DDR4_1_DQ8
AN14 DDR4_1_DQ9
AH9 DDR4_1_DQS0_C
AG9 DDR4_1_DQS0_T
AL16 DDR4_1_DQS1_C
AK16 DDR4_1_DQS1_T
AT13 DDR4_1_DQS2_C
AR13 DDR4_1_DQS2_T
AV17 DDR4_1_DQS3_C
AU17 DDR4_1_DQS3_T
AP22 DDR4_1_DQS4_C
AN22 DDR4_1_DQS4_T
AV21 DDR4_1_DQS5_C
AV22 DDR4_1_DQS5_T
AH20 DDR4_1_DQS6_C
AG20 DDR4_1_DQS6_T
AL21 DDR4_1_DQS7_C
AK21 DDR4_1_DQS7_T
AH15 DDR4_1_DQS8_C
AH16 DDR4_1_DQS8_T
AR11 DDR4_1_ODT
AM8 DDR4_1_PAR
AN12 DDR4_1_RESET_N
AV11 DDR4_1_TEN
Table 15 : Complete Pinout Table (continued on next page)
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
Page 29
