ADM-PCIE-9V3 User Manual
Complete Pinout Table
ad-ug-1322_v2_7.pdf
Pin
Signal Name
Number
AF4 PCIE_TX8_PIN_N
AF5 PCIE_TX8_PIN_P
AH4 PCIE_TX9_PIN_N
AH5 PCIE_TX9_PIN_P
AJ31 PERST_1V8_0_L
AH29 PERST_1V8_1_L
J30 POWER9_SCL_1V8
K30 POWER9_SDA_1V8
P30 PPS_BUF_1V8
B30 PRE_DETECT_1V8
V10 PROGRAM_B_1V8
U8 PUDC_B
F29 QSFP0_MODPRS_L
G39 QSFP0_RX0_N
G38 QSFP0_RX0_P
E39 QSFP0_RX1_N
E38 QSFP0_RX1_P
C39 QSFP0_RX2_N
C38 QSFP0_RX2_P
B37 QSFP0_RX3_N
B36 QSFP0_RX3_P
D31 QSFP0_SEL_1V8_L
F36 QSFP0_TX0_N
F35 QSFP0_TX0_P
D36 QSFP0_TX1_N
D35 QSFP0_TX1_P
C34 QSFP0_TX2_N
C33 QSFP0_TX2_P
A34 QSFP0_TX3_N
A33 QSFP0_TX3_P
F33 QSFP1_MODPRS_L
R39 QSFP1_RX0_N
R38 QSFP1_RX0_P
N39 QSFP1_RX1_N
N38 QSFP1_RX1_P
Table 15 : Complete Pinout Table (continued on next page)
Bank Voltage
MGT
MGT
MGT
MGT
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT
1.8
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT
1.8
MGT
MGT
MGT
MGT
Page 33
