Alpha Data ADM-PCIE-9V3 User Manual page 28

Page 24
Pin
Signal Name
Number
C16 DDR4_0_DQ25
B16 DDR4_0_DQ26
A14 DDR4_0_DQ27
B17 DDR4_0_DQ28
B14 DDR4_0_DQ29
M9 DDR4_0_DQ3
D16 DDR4_0_DQ30
D15 DDR4_0_DQ31
F18 DDR4_0_DQ32
F20 DDR4_0_DQ33
F19 DDR4_0_DQ34
D21 DDR4_0_DQ35
E18 DDR4_0_DQ36
G19 DDR4_0_DQ37
E21 DDR4_0_DQ38
G20 DDR4_0_DQ39
M10 DDR4_0_DQ4
D18 DDR4_0_DQ40
B22 DDR4_0_DQ41
A19 DDR4_0_DQ42
A18 DDR4_0_DQ43
C19 DDR4_0_DQ44
B19 DDR4_0_DQ45
A22 DDR4_0_DQ46
C18 DDR4_0_DQ47
G22 DDR4_0_DQ48
J20 DDR4_0_DQ49
K11 DDR4_0_DQ5
H19 DDR4_0_DQ50
J19 DDR4_0_DQ51
H18 DDR4_0_DQ52
J18 DDR4_0_DQ53
G21 DDR4_0_DQ54
K18 DDR4_0_DQ55
L20 DDR4_0_DQ56
Table 15 : Complete Pinout Table (continued on next page)
ADM-PCIE-9V3 User Manual
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
Complete Pinout Table
