ADM-PCIE-9V3 User Manual
connector on the front panel. Contact sales@alpha-data.com for front panel connector options.
For pin locations, see signal name PPS_BUF_1V8 in
The signal is isolated through a optical isolator part number ACPL-M61L with a 739 ohm of series resistance.
3.11 User EEPROM
A 2Kb I2C user EEPROM is provided for storing MAC addresses or other user information. The EEPROM is part
number M24C02-RMC6TG.
The address pins A2, A1, and A0 are all strapped to a logical '0'.
Write protect (WP), Serial Clock (SCL), and Serial Data (SDA) pin assignments can be found in
Table
with the names SPARE_WP, SPARE_SCL, and SPARE_SDA respectively.
WP, SDA, and SCL signals all have external pull-up resistors on the card.
Functional Description
ad-ug-1322_v2_7.pdf
Complete Pinout
Table.
Complete Pinout
Page 19
