Alpha Data ADM-PCIE-9V3 User Manual page 30

Page 26
Pin
Signal Name
Number
K16 DDR4_0_DQS8_C
K17 DDR4_0_DQS8_T
A10 DDR4_0_ODT
G7 DDR4_0_PAR
F7 DDR4_0_RESET_N
J10 DDR4_0_TEN
AN9 DDR4_1_A0
AM9 DDR4_1_A1
AR8 DDR4_1_A10
AL10 DDR4_1_A11
AP8 DDR4_1_A12
AK11 DDR4_1_A13
AP9 DDR4_1_A14
AV10 DDR4_1_A15
AT11 DDR4_1_A16
AL8 DDR4_1_A17
AP11 DDR4_1_A2
AU9 DDR4_1_A3
AT10 DDR4_1_A4
AL12 DDR4_1_A5
AM12 DDR4_1_A6
AM10 DDR4_1_A7
AL11 DDR4_1_A8
AP7 DDR4_1_A9
AV9 DDR4_1_ACT_N
AR10 DDR4_1_ALERT_N
AN11 DDR4_1_BA0
AR9 DDR4_1_BA1
AP12 DDR4_1_BG0
AN10 DDR4_1_BG1
AW13 DDR4_1_C0
AU10 DDR4_1_C1
AW11 DDR4_1_C2
AN7 DDR4_1_CK_C
AM7 DDR4_1_CK_T
Table 15 : Complete Pinout Table (continued on next page)
ADM-PCIE-9V3 User Manual
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
Complete Pinout Table
