MODELS LISTED IN THIS MANUAL (AND DETERMINING THEIR RESPECTIVE CASE DIMENSIONS)
DETERMINING YOUR MODEL AND ITS CASE DIMENSIONS:
Note 1. Your model number can be found on serial label at rear of case (near main power switch).
Note 2. Dimensions of most models can be found at www.structuralconcepts.com. Simply enter
the case model number into the Product Number Search box. Click the product specification link
for complete dimensions.
Note 3. If your specific model is not found, contact technical service (phone number is listed at
Technical Service section in this manual) for dimensions.
Note 4. CDRs (Customer Design Requests) are listed with a 4-digit number. All CDR dimensions
are very similar (and some identical) to standard model dimensions.
THIS OPERATING MANUAL ENCOMPASSES THE FOLLOWING MODELS (AND/OR THEIR
RESPECTIVE CDRs):
2287 2595 2613 2613A 2613B 2852C 3153 3916 HVK3696RSS.5159A
HVK36144RSS.5159B HVK48RSS HVK56RSS HVK74RSS
HVK74RSS.5142A HVK96RSS HVK96RSS.5142 HVK4296RSS
HV28RSS HV28RSS.3635B HV38RSS HV38RSSRD HV48RSS
HV48RSS.2917 HV48RSS.3620 HV48RSS.3635A HV48RSS.3735A
HV48RSS.5536 HV48RSS.5975 HV56RSS HV56RSS.3928A
HV56RSS.3935A HV56RSS.4203 HV56RSS.5010 HV56RSS.5381
HV74RSS HV74RSS.2846B HV74RSS.2852 HV74RSS.3905B
HV74RSS.3928 HV74RSS.3941 HV74RSS.3941A HV74RSS.4104
HV74RSS.4444 HV74RSS.4447A HV74RSS.5009 HV74RSS.5028
HV74RSS.5287 HV74RSS.5543 HV96RSS HV96RSS.3905
HV96RSS.4070 HV96RSS.4105 HV96RSS.4645 HV96RSS.5161
HV96RSS.5289 HV96RSS.5290 HV96RSS.5975C HV112RSS
HV112RSS.2852D HV114RSS HV144RSS HV34144RSS
HV34144RSS.4993 HV34144RSS.4993A HV3638RSS HV3648RSS
HV3656RSS HV3674RSS HV3674RSS.4922 HV3674RSS.5954
HV3696RSS HV36112RSS HV36112RSS.4922B HV36112RSS.4992B
HV36112RSS.4863A HV4256RSS HV4274RSS HV4296RSS
HV5656RSS HV5656RSS.5382 HV7439RSS HV38RSSRD
HV48RSSRD HV56RSSRD HV74RSSRD HV96RSSRD HV112RSSRD
HVLD48RSS.4125 RG2Z5080 HV74RSS.6527 HV96RSS.6527
HV74RSS.6533 HV96RSS.6533 #80-02791 (DOC OPTION #80-02791)
