Transition Networks
Rate Limiting
Management
DHCP Server
Remote Monitoring (RMON)
Port Mirroring
UPnP
sFlow
IEEE 802.1ab (LLDP)
Web GUI Interface
CLI (Command Line Interface)
Dual Image
SNMP
Firmware Upgrade
NTP
Other Management
Switch Architecture
The switch performs a wire‐speed, non‐blocking switching fabric. This allows wire‐speed transport of multiple
packets at low latency on all ports simultaneously. The switch also features full‐duplex capability on all ports,
which effectively doubles the bandwidth of each connection.
This switch uses store‐and‐forward technology to ensure maximum data integrity. With this technology, the
entire packet must be received into a buffer and checked for validity before being forwarded. This prevents
errors from being propagated throughout the network.
Network Management Options
The switch can be managed over the network with a web browser or Telnet application. The switch includes a
built‐in network management agent that allows it to be managed in‐band using SNMP or RMON (Groups 1, 2, 3,
9) protocols.
33681 Rev. B
 Ingress policer
 Egress shaping and rate control
 Per port
Support DHCP server to assign IP to DHCP clients
Embedded RMON agent supports RMON groups 1,2,3,9 (history, statistics, alarms,
and events) for enhanced traffic management, monitoring and analysis
Traffic on a port can be mirrored to another port for analysis with a network
analyzer or RMON probe. Up to N‐1 (N is Switch's Ports) ports can be mirrored to
single destination port. A single session is supported.
The Universal Plug and Play Forum, an industry group of companies working to
enable device‐to‐device interoperability by promoting Universal Plug and Play.
The industry standard for monitoring high speed switched networks. It gives
complete visibility into the use of networks enabling performance optimization,
accounting/billing for usage, and defense against security threats
 Used by network devices for advertising their identities, capabilities, and
neighbors on an IEEE 802ab local area network
 Support LLDP‐MED extensions
Built‐in switch configuration utility for browser‐based device configuration
For users to configure/manage switches in command line modes
Independent primary and secondary images for backup while upgrading
SNMP version1, 2c and 3 with support for traps, and SNMP version 3
user‐based security model (USM)
 Web browser upgrade (HTTP/ HTTPs) and TFTP
 Upgrade through console port as well
Network Time Protocol (NTP) is a networking protocol for clock synchronization
between computer systems over packet‐switched networks
 HTTP/HTTPs; SSH
 DHCP Client/ DHCPv6 Client
 Cable Diagnostics
 Ping / Traceroute
 Syslog
 Telnet Client
 IPv6 Management
