Contents
Safety Warnings and Cautions . .................................................................................................................................. 2
Compliance and Safety Statements ....................................................................................................................... 3
Overview . ................................................................................................................................................................... 5
About This Guide ................................................................................................................................................... 5
Key Features .............................................................................................................................................................. 5
Benefits .................................................................................................................................................................. 5
Specifications ......................................................................................................................................................... 6
Front Panel............................................................................................................................................................... 10
Port and System Status LEDs . ............................................................................................................................... 10
Installation ............................................................................................................................................................... 11
Unpacking ............................................................................................................................................................ 11
Selecting a Site ..................................................................................................................................................... 11
Troubleshooting . ...................................................................................................................................................... 18
Related Manuals ...................................................................................................................................................... 18
Optional DC Power Supply . ...................................................................................................................................... 19
Industrial Power Supply 25104 (Mean Well SDR-240-48) ................................................................................... 19
25131 - Industrial DIN-rail Mount Power Supply (MEANWELL SDR-75-48) ........................................................ 20
DC Power Supply Wiring ...................................................................................................................................... 21
Declaration of Conformity ....................................................................................................................................... 21
Contact Us ............................................................................................................................................................... 22
Warranty . ................................................................................................................................................................. 22
Compliance and Safety Statements
This equipment has been tested and found to comply with the limits for a Class A computing device
FCC-CLASS A :
pursuant to Subpart J of part 15 of FCC Rules, which are designed to provide reasonable protection against such interference
when operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense. You are cautioned that changes or modifications not
expressly approved by the party responsible for compliance could void your authority to operate the equipment.
You may use unshielded twisted-pair (UTP) for RJ-45 connections - Category 3 or better for 10 Mbps connections, Category 5
or better for 100 Mbps connections, Category 5, 5e, or 6 for 1000 Mbps connections. For fiber optic connections, you may
use 50/125 or 62.5/125 micron multimode fiber or 9/125 micron single-mode fiber.
CE MARK / DECLARATION OF CONFORMANCE FOR EMI AND SAFETY (EEC) :
found to comply with the protection requirements of European Emission Standard EN55022/EN61000-3 and the Generic
European Immunity Standard EN55024. SM24DPB tested and found to be in conformity with IEC 60950-1(ed.2), IEC 60950-
1(ed.2);am1, IEC 60950-1(ed.2);am2. Additionally evaluated to EN 60950-1:2006/A11:2009/A1:2010/A12:2011/A2:2013;
National Differences specified in the CB Test Report.
EMC
European Standard EN 300 386 V1.6.1:2012,
EN 61000-3-2:2006/A1:2009 and /A2:2009, EN 61000-3-3:2008
EN 55024:2010 (IEC 61000-4-2 Edition 2.0 2008-12,
IEC 61000-4-3 Edition 3.2 2010-04, IEC 6100-4-4 Edition 3.0 2012-04,
IEC 61000-4-5 Edition 2.0 2005-11, IEC 6100-4-6 Edition 3.0 2008-10,
IEC 61000-4-8 Edition 2.0 2009-09, IEC 61000-4-11 Edition 2.0 2004-03 and
Australian Standard AS/NZ CISPR 22:2009/A1:2010 Class A
33681 Rev. B
EN55032:2012
https://www.transition.com
SM24DPB Install Guide
This equipment has been tested and
Page 3 of 24
