Transition Networks SM24-100SFP-AH Specifications

24-port
Transition Networks
managed switches
24 100BASE-X SFP Ports, 2 10/100/1000 RJ-45 Ports, 2
Gigabit Combo Ports Managed Switch
802.3ah OAM
Supports SNMP v1, v2 & v3
STP, RSTP and MSTP
Flexible Uplink Options: In addition to the (24)
100BASE-X ports the SM24-100SFP-AH has combo Gigabit
uplink ports that allow copper or fiber connections to be
used, depending on the network environment. The fiber
ports are SFP and can accommodate a wide range of
transceivers for your uplink requirements.
Carrier Ethernet Specific Software: The SM24-100SFP-
AH switch was designed for use with Carrier Ethernet.
Feature enhancements such as 802.3ah, Q-in-Q, Carrier
Class Rate-Limit, QoS and subscriber isolation were added
to help service providers deploy, manage and secure the
network services they are delivering.
Single IP Management for 36 Switches: The SM24-
100SFP-AH is managed as a single switch and has a single
IP address. Up to 36 of the SM24-100SFP-AH switches
can be virtually stacked and managed as a single switch
while using only one IP address.
Specifications
Standards Compliance
IEEE 802.1D Spanning Tree Protocol and traffic priorities
IEEE 802.1p Priority tags
IEEE 802.1Q VLAN
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1v Protocol-based VLANs
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1X Port Authentication
IEEE 802.3-2005
Ethernet, Fast Ethernet, Gigabit Ethernet
Full-duplex flow control
Link Aggregation Control Protocol
IEEE 802.3ac VLAN tagging
DHCP Client (RFC 1541)
HTTPS
IGMP (RFC 1112)
IGMPv2 (RFC 2236)
Management Information Bases
RADIUS+ (RFC 2618)
RMON (RFC 1757 groups 1,2,3,9)
SNMP (RFC 1157)
SNMPv2 (RFC 2571)
SNMPv3 (RFC DRAFT 3414, 3410, 2273, 3411, 3415)
SNTP (RFC 2030)
SSH (Version 2.0)
TFTP (RFC 1350)
Physical Ports 24 100BASE-X SFP ports
2 10/100/1000 BASE-TX ports
2 Combo Gigabit Ethernet
(RJ-45/SFP) ports
1 RJ-45 Console port
MAC Address 17K MAC address table
Jumbo packet support 10Kbytes jumbo packet size
(on Gigabit ports)
Packet Buffer Size .75MB
Backplane Bandwidth 12.8 Gbps
LEDs System: Power
Port: Status
Power Consumption 54 W maximum
AC Input 100 to 240 V, 50-60 Hz, 2 A
Temperature Operating: 0° to 50°C (32° to 122° F)
Storage: -40° to 70°C (-40° to 158° F)
Operating Humidity 10% to 90% (non-condensing)
Dimensions 44 x 440 x 230 mm
(1.73 x 17.3 x 9 in.)
Weight 3.5 kg (7.7 lbs)
Certifications FCC Class A, CE Mark, UL, cUL
100BASE-X 802.3ah OAM Switch
Advanced Quality of Service (QoS)
Enhanced Security Features
IGMP v1, v2 and v3
Features
Authentication: Local, RADIUS, TACACS, Port (802.1X,
MAC Authentication, Web Authentication), HTTPS, SSH,
Port Security
Access Control Lists: IP, MAC; 1000 rules per system
DHCP Client
Port Configuration: 100BASE-FX: 100 Mbps full duplex
1000BASE-T: 10/100 Mbps at half/full duplex,
1000 Mbps at full duplex 1000BASE-SX/LX/LH
- 1000 Mbps at full duplex (SFP)
Flow Control: Full Duplex: IEEE 802.3-2005
Half Duplex: Back pressure
Broadcast Storm Control: Traffic throttled above a
critical threshold
Port Mirroring: Multiple source ports,
one destination port
Rate Limits: Input limit, Output limit
Port Trunking:
Static trunks (Cisco EtherChannel compliant)
Dynamic trunks (Link Aggregation Control Protocol)
Spanning Tree Algorithm:
Spanning Tree Protocol (STP, IEEE 802.1D)
Rapid Spanning Tree Protocol (RSTP, IEEE 802.1w)
Multiple Spanning Tree Protocol (MSTP, IEEE 802.1s)
VLAN Support: Up to 255 groups; port-based
or tagged (802.1Q),Private VLANs,Protocol-based VLANs
Class of Service: Supports 4 levels of priority and
Weighted Round Robin Queueing (which can be configured
by VLAN tag or port), Layer 3/4 priority mapping: IP DSCP
Multicast Filtering: IGMP Snooping (Layer 2)
Multicast VLAN Registration
Quality of Service: DiffServ supports class maps, policy
maps, and service policies
BOOTP client
SNTP (Simple Network Time Protocol)
SNMP (Simple Network Management Protocol)
RMON (Remote Monitoring, groups 1,2,3,9)
SMTP Email Alerts
DHCP Snooping
IP Source Guard
IP Clustering

Management Features

In-Band Management: Telnet, Web-based HTTP or
HTTPS, SNMP manager, or Secure Shell
Out-of-Band Management: RS-232 DB-9 console port
Software Loading: TFTP in-band or XModem out-of-band
SNMP: Management access via MIB database,
Trap management to specified hosts
RMON: Groups 1, 2, 3, 9
(Statistics, History, Alarm, Event)
SM24-100SFP-AH
Next Generation Switch
The SM24-100SFP-AH features a 1U
form factor consisting of (24)
100Base-X SFP ports, (2)
10/100/1000 RJ-45 ports and (2)
Gigabit combo ports. The 24 SFP
ports accept industry standard
100BASE-X optical transceivers.
The SM24-100SFP-AH switch also
includes Carrier Ethernet specific
software, QoS and Management
features which enable service
providers to deliver secure services
while checking end to end
connectivity for customers. The
SM24-100SFP–AH switch is a next
generation switch designed to fulfill
the needs of service providers.

Ordering Info

SM24-100SFP-AH
24 100BASE-X SFP Ports, 2
10/100/1000 RJ-45 Ports, 2 Gigabit
Combo Ports Managed Switch
Includes 19" Rackmount Kit
