PCI-DIO48H User's Guide

Main Connector and Pin Out

Connector type
Compatible cables
Compatible accessory
products
Pin Signal name
50 GND
48 FIRSTPORTC Bit 0
46 FIRSTPORTC Bit 2
44 FIRSTPORTC Bit 4
42 FIRSTPORTC Bit 6
40 FIRSTPORTB Bit 0
38 FIRSTPORTB Bit 2
36 FIRSTPORTB Bit 4
34 FIRSTPORTB Bit 6
32 FIRSTPORTA Bit 0
30 FIRSTPORTA Bit 2
28 FIRSTPORTA Bit 4
26 FIRSTPORTA Bit 6
24 SECONDPORTC Bit 0
22 SECONDPORTC Bit 2
20 SECONDPORTC Bit 4
18 SECONDPORTC Bit 6
16 SECONDPORTB Bit 0
14 SECONDPORTB Bit 2
12 SECONDPORTB Bit 4
10 SECONDPORTB Bit 6
8 SECONDPORTA Bit 0
6 SECONDPORTA Bit 2
4 SECONDPORTA Bit 4
2 SECONDPORTA Bit 6
Table 5-6. Main connector specifications
50-pin, high-density IDC male header connector.
C50FF-x
CIO-MINI50
CIO-SPADE50
SCB-50
CIO-ERB24
CIO-SERB24/FD
CIO-ERB48
CIO-SERB48
SSR-RACK24
SSR-RACK48
5-2
Pin Signal name
49 +5V
47 FIRSTPORTC Bit 1
45 FIRSTPORTC Bit 3
43 FIRSTPORTC Bit 5
41 FIRSTPORTC Bit 7
39 FIRSTPORTB Bit 1
37 FIRSTPORTB Bit 3
35 FIRSTPORTB Bit 5
33 FIRSTPORTB Bit 7
31 FIRSTPORTA Bit 1
29 FIRSTPORTA Bit 3
27 FIRSTPORTA Bit 5
25 FIRSTPORTA Bit 7
23 SECONDPORTC Bit 1
21 SECONDPORTC Bit 3
19 SECONDPORTC Bit 5
17 SECONDPORTC Bit 7
15 SECONDPORTB Bit 1
13 SECONDPORTB Bit 3
11 SECONDPORTB Bit 5
9 SECONDPORTB Bit 7
7 SECONDPORTA Bit 1
5 SECONDPORTA Bit 3
3 SECONDPORTA Bit 5
1 SECONDPORTA Bit 7
Specifications
