  • Page 2 PCI-DAC6702 and PCI-DAC6703 High Resolution Analog Output and Digital I/O User's Guide Document Revision 1, May, 2005 © Copyright 2005, Measurement Computing Corporation...
  • Page 3 Measurement Computing. Thank you for choosing a Measurement Computing product—and congratulations! You own the finest, and you can now enjoy the protection of the most comprehensive warranties and unmatched phone tech support. It’s the embodiment of our...
  • Page 4 Information furnished by Measurement Computing Corporation is believed to be accurate and reliable. However, no responsibility is assumed by Measurement Computing Corporation neither for its use; nor for any infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any patent or copyrights of Measurement Computing Corporation.
  • Page 5: Table Of Contents

    Table of Contents Preface About this User's Guide ........................v What you will learn from this user's guide ......................v Conventions in this user's guide .........................v Where to find more information ........................vi Chapter 1 Introducing the PCI-DAC6700 Series Boards................. 1-1 Overview: PCI-DAC6700 Series board features .................... 1-1 Software features ............................
  • Page 6: Preface

    This user’s guide also refers you to related documents available on our web site, and to technical support resources. Conventions in this user's guide The term PCI-DAC6700 Series is used throughout this manual when referring to both the PCI-DAC6702 and PCI-DAC6703 boards. For more information on …...
  • Page 7: Where To Find More Information

    Where to find more information The following electronic documents provide helpful information relevant to the operation of the PCI- DAC6700 Series boards. MCC's Specifications: PCI-DAC6702 and PCI-DAC6703 (the PDF version of Chapter 5 in this guide) is available on our web site at www.mccdaq.com/pdfs/PCI-DAC670x.pdf.
  • Page 8: Introducing The Pci-Dac6700 Series Boards

    Introducing the PCI-DAC6700 Series Boards Overview: PCI-DAC6700 Series board features This manual explains how to install and use your PCI-DAC6702 and PCI-DAC6703 board. This manual refers to these boards collectively as PCI-DAC6700 Series boards. PCI-DAC6700 Series boards are high-resolution analog output and digital I/O boards designed for PCI bus-compatible computers.
  • Page 9: Software Features

    PCI-DAC6702 and PCI-DAC6703 User's Guide Introducing the PCI-DAC6700 Series Boards PCI-DAC6700 Series functions are illustrated in the block diagram shown here. PCI-DAC6703 x 16 PCI-DAC6702 x 8 Voltage Main 16-Bit Output Voltage Circuit Circuit nvRAM Address/ Data Control DIO (7:0)
  • Page 10: Installing The Pci-Dac6700 Series

    PCI-DAC6702 board or PCI-DAC6703 board PCI-DAC6702 PCI-DAC6703 Software The Measurement Computing Data Acquisition Software CD contains the following software: InstaCal installation, calibration, and test utility TracerDAQ suite of virtual instruments SoftWIRE for VS .NET SoftWIRE MCC DAQ Components for .NET (installed with SoftWIRE for VS .NET)
  • Page 11: Optional Components

    Remove the board from the container. Never touch the exposed pins or circuit connections on the board. If your board is damaged, notify Measurement Computing Corporation immediately by phone, fax, or e- mail. For international customers, contact your local distributor where you purchased the board.
  • Page 12: Installing The Software

    PCI-DAC6702 and PCI-DAC6703 User's Guide Installing the PCI-DAC6700 Series If any items are missing or damaged, contact Measurement Computing Corp. by phone, fax, or e-mail: Phone: 508-946-5100 and follow the instructions for reaching Tech Support. Fax: 508-946-9500 to the attention of Tech Support Email: techsupport@measurementcomputing.com...
  • Page 13: Connecting The Board For I/O Operations

    PCI-DAC6702 and PCI-DAC6703 User's Guide Installing the PCI-DAC6700 Series Connecting the board for I/O operations Connectors, cables – main I/O connector Table 2-1 lists the board connectors, applicable cables, and compatible accessory products for the PCI- DAC6700 Series. Table 2-1. Board connectors, cables, and accessory equipment...
  • Page 14: Pinout - Main I/O Connector

    PCI-DAC6702 and PCI-DAC6703 User's Guide Installing the PCI-DAC6700 Series Pinout – main I/O connector The main I/O connector pinouts for each board are shown in the following tables. Note that the DIO[7:0] signals are provided in two locations in order to provide flexibility for applications which use the C100HD50-x ribbon cable.
  • Page 15 PCI-DAC6702 and PCI-DAC6703 User's Guide Installing the PCI-DAC6700 Series Table 2-3. PCI-DAC6702 connector pin out Signal name Signal name • • AGND AGND • • VCH0 AGND0 • • AGND VCH1 • • AGND1 • • AGND VCH2 • •...
  • Page 16: Cabling

    PCI-DAC6702 and PCI-DAC6703 User's Guide Installing the PCI-DAC6700 Series Cabling Strain relief is stamped “Pins 1-50”. Pins 1-50 are on the long side of the “D” connector. The red stripe identifies pin # 1 Pins 51-100 are on the short side of Strain relief is the “D”...
  • Page 17: Field Wiring And Signal Termination Accessories

    PCI-DAC6702 and PCI-DAC6703 User's Guide Installing the PCI-DAC6700 Series Field wiring and signal termination accessories You can use the following BNC and screw terminal boards to terminate field signals and route them into the PCI-DAC6700 Series using the C100HD50-x cable: BNC-16SE –...
  • Page 18: Programming And Software Applications

    After following the installation instructions in Chapter 2, your board should now be installed and ready for use. Programming languages Measurement Computing’s Universal Library® provides access to board functions from a variety of Windows programming languages. If you are planning to write programs, or would like to run the example ...
  • Page 19: Calibrating The Board

    Chapter 4 Calibrating the Board You should calibrate the board using the InstaCal utility software after the board has fully warmed up. The recommended warm-up time is 15 minutes. For best results, calibrate the board immediately before use. The high resolution analog components on the board are temperature-sensitive, so calibrating the board before use ensures that your board is operating with the optimum calibration values.
  • Page 20: Specifications

    Table 5-1. Analog output specifications D/A converter type Enhanced R-2R Resolution 16-bits, 1 in 65536 Number of channels PCI-DAC6703 16 voltage PCI-DAC6702 8 voltage ±1 LSB max Monotonicity 16-bits, guaranteed after calibration Update rate, max PCI-DAC6703 1111 S/s per channel...
  • Page 21: Analog Output Calibration

    PCI-DAC6702 and PCI-DAC6703 User's Guide Specifications Table 5-4. Relative accuracy Range Relative Accuracy ±10 V ±1.0 LSB, max Relative accuracy is defined as the measured deviation from a straight line drawn between measured endpoints of the transfer function. Analog output calibration Table 5-5.
  • Page 22: Mechanical

    PCI-DAC6702 and PCI-DAC6703 User's Guide Specifications Mechanical Table 5-9. Mechanical specifications Card dimensions PCI half card: 174.4 mm (L) x 106.9 mm (W) x18.4 mm (H) Form factor Universal PCI keying. Compatible with either 3.3 V or 5 V PCI signaling environments.
  • Page 23 PCI-DAC6702 and PCI-DAC6703 User's Guide Specifications Table 5-11. PCI-DAC6703 pin out Signal Name Signal Name AGND AGND VCH0 AGND0 AGND VCH1 AGND1 AGND VCH2 AGND2 AGND VCH3 AGND3 AGND VCH4 AGND4 AGND VCH5 AGND5 AGND VCH6 AGND6 AGND VCH7 AGND7...
  • Page 24 PCI-DAC6702 and PCI-DAC6703 User's Guide Specifications Table 5-12. PCI-DAC6702 pin out Signal Name Signal Name AGND AGND VCH0 AGND0 AGND VCH1 AGND1 AGND VCH2 AGND2 AGND VCH3 AGND3 AGND VCH4 AGND4 AGND VCH5 AGND5 AGND VCH6 AGND6 AGND VCH7 AGND7...
  • Page 25 Middleboro, MA 02346 Category: Electrical equipment for measurement, control and laboratory use. Measurement Computing Corporation declares under sole responsibility that the product PCI-DAC6702 to which this declaration relates is in conformity with the relevant provisions of the following standards or...
  • Page 26 Middleboro, MA 02346 Category: Electrical equipment for measurement, control and laboratory use. Measurement Computing Corporation declares under sole responsibility that the product PCI-DAC6703 to which this declaration relates is in conformity with the relevant provisions of the following standards or...
  • Page 27 Measurement Computing Corporation 16 Commerce Boulevard, Middleboro, Massachusetts 02346 (508) 946-5100 Fax: (508) 946-9500 E-mail: info@mccdaq.com www.mccdaq.com...
