PCI-DAS08 User's Guide

Power consumption

Parameter
+5 V operating (A/D converting to FIFO)
+12 V
-12 V

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Main connector and pin out

Parameter
Connector type
Compatible cables
Compatible accessory products
(with C37FF-x cable)
Compatible accessory products
(with C37FFS-x cable)
Table 4-4. Power consumption specifications
Specification
251 mA typical, 436 mA max
13 mA typical, 19 mA max
17 mA typical, 23 mA max
Table 4-5. Environmental specifications
Specification
0 to 50 °C
-20 to 70 °C
0 to 90% non-condensing
Table 4-6. Main connector specifications
Specification
37-pin male "D" connector
C37FF-x cable
C37FFS-x cable
CIO-MINI37
SCB-37
ISO-RACK08
CIO-MINI37
SCB-37
ISO-RACK08
CIO-EXP16
CIO-EXP32
CIO-EXP-GP
CIO-EXP-BRIDGE16
CIO-EXP-RTD16
4-3
Specifications
