PCI-DAC6702 and PCI-DAC6703 User's Guide

Mechanical

Card dimensions PCI half card: 174.4 mm (L) x 106.9 mm (W) x18.4 mm (H)
Form factor Universal PCI keying. Compatible with either 3.3 V or 5 V PCI signaling environments.

Main connector and pin out

Connector type
Compatible cables
Compatible accessory products
(with C100HD50-x cable)
Compatible accessory products
(with C100MMS-x cable)
Table 5-9. Mechanical specifications
Table 5-10. Main connector specifications
Shielded SCSI 100 D-Type
C100HD50-x, unshielded ribbon cable.
x = 3 or 6 feet
C100MMS-x, shielded round cable.
x = 1, 2, or 3 meters
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
SCB-100
BNC-16DI-FE
5-3
Specifications
