PCI-DIO48H User's Guide
Optional components
If you ordered any of the following products with your board, they should be included with your
shipment.
Universal Library
Universal Library™ Data Acquisition and Control Programming Tools (also includes the InstaCal
utility, the Universal Library User's Guide, and the Universal Library Function Reference)
Cables
Signal termination and conditioning accessories
MCC provides signal termination products for use with the PCI-DIO48H. Refer to
termination and conditioning
Unpacking the board
The PCI-DIO48H board is shipped in an antistatic container to prevent damage by an electrostatic
discharge. To avoid such damage, perform the following procedure when unpacking and handling your
board.
1.
Before opening the antistatic container, ground yourself with a wrist-grounding strap or by holding
onto a grounded object (such as the computer chassis).
2.
Touch the antistatic container to the computer chassis before removing the board from the container.
3.
Remove the board from the container. Never touch the exposed pins or circuit connections on the
board.
If your board is damaged, notify Measurement Computing Corporation immediately by phone, fax, or
e-mail. For international customers, contact your local distributor where you purchased the board.
Phone: 508-946-5100 and follow the instructions for reaching Tech Support.
Fax: 508-946-9500 to the attention of Tech Support
Email:
techsupport@measurementcomputing.com
Installing the software
Install the software included with your board before you install the hardware. Installing the software first
ensures that the information required for proper board detection is installed and available at boot up.
Refer to the DAQ Software Quick Start for instructions on installing the software on the Measurement
Computing Data Acquisition Software CD. This booklet is shipped with the hardware, and is also
available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.
on page 2-4 for a complete list of compatible accessory products.
2-2
Installing the PCI-DIO48H
