Specifications

Typical for 25 °C unless otherwise specified.

Digital Input / Output

Digital Type
Output:
Input:
Configuration
Number of I/O
Output High
Output Low
Input High
Input Low
Power-up / reset state
Pull-Up/Pull-Down Resistors

Power Consumption

+5V Operating

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions

Software

Software Support
Table 5-1. Digital I/O specifications
8255 emulation, Mode 0
74S244
74LS373
4 banks of 8, 4 banks of 4, programmable by bank as input or output
48
2.4 volts min @ -15mA
0.5 volts max @ 64 mA
2.0 volts min, 7 volts absolute max
0.8 volts max, -0.5 volts absolute min
Input mode (high impedance)
SIP resistor locations provided for pull-up or pull-down configuration.
Table 5-2. Power consumption specifications
1.2 A typical, 1.6 A max
Table 5-3. Environmental specifications
0 to 50°C
-20 to 70°C
0 to 90% non-condensing
Table 5-4. Mechanical specifications
174.7 mm L x 106.6 mm H x 14.5mm W
Table 5-5. Software specifications
Universal Library and InstaCal
5-1
Chapter 5
