Specifications
Typical for 25 °C unless otherwise specified.
Specifications in italic text are guaranteed by design

Power consumption

+5V Operating

Digital Input / Output

Digital type (main connector)
Output
Input
Configuration
Number of channels
Output high
Output low
Input high
Input low
Power-up / reset state
Miscellaneous

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions

Main connector and pin out

Connector type
Compatible cables
Compatible accessory products
with the C100FE-x cable
Compatible accessory products
with the C100FF-x cable
Table 1. Power consumption specifications
1.13 A typical, 1.80 A max
Table 2. Digital I/O specifications
8255 mode 0 emulation
74S244
74LS373
4 banks of 8, 4 banks of 4, programmable by bank as input or output
48 I/O
2.4 volts min @ -15 mA
0.5 volts max @ 64 mA
2.0 volts min, 7 volts absolute max
0.8 volts max, -0.5 volts absolute min
Input mode (high impedance)
Locations provided for installation of pull-up or pull-down resistors
Table 3. Environmental specifications
0 to 70 °C
-40 to 100 °C
0 to 90% non-condensing
Table 4. Mechanical specifications
174.8 mm (L) x 106.7 mm (W) x 21.6 mm (H)
6.88" (L) x 4.2" (W) x 0.85" (H)
Table 5. Main connector specifications
100-pin high density
C100FE-x cable
C100FF-x cable
SSR-PB24 (2)
CIO-MINI50 (2)
CIO-SPADE50 (2)
CIO-TERM100 (1)
SCB-50 (1)
