PCI-DIO48H User's Guide
Installing the hardware
The PCI-DIO48H board is completely plug-and-play. There are no switches or jumpers to set on the
board. Configuration is controlled by your system's BIOS. To install your board, follow the steps below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to
install the MCC DAQ software before you install your board. Refer to the DAQ Software Quick Start for
instructions on installing the software.
1.
Turn your computer off, open it up, and insert your board into an available PCI slot.
2.
Close your computer and turn it on.
If you are using an operating system with support for plug-and-play (such as Windows 2000 or
Windows XP), a dialog box pops up as the system loads indicating that new hardware has been
detected. If the information file for this board is not already loaded onto your PC, you will be
prompted for the disk containing this file. The MCC DAQ software contains this file. If required,
insert the Measurement Computing Data Acquisition Software CD and click
3.
To test your installation and configure your board, run the InstaCal utility installed in the previous
section. Refer to the DAQ Software Quick Start that came with your board for information on how to
initially set up and load InstaCal.
Connecting the board for I/O operations
Connectors, cables – main I/O connector
Table 2-1
lists the board connectors, applicable cables and compatible accessory boards.
Connector type
Compatible cables
Compatible accessory products with
the C50FF-x cable
The PCI-DIO48H board has a 50-pin, high-density male header connector that is accessible through the
slot in the expansion bracket. Connector pin outs are listed in Ta
Information on signal connections
General information regarding signal connection and configuration is available in the Guide to Signal
Connections. This document is available on our web site at www.mccdaq.com/signals/signals.pdf.
Caution! When connecting a cable to the board's I/O connector, make sure that the arrow indicating
pin 1 on the board connector lines up with the arrow indicating pin 1 on the cable connector.
Incorrectly connected cables can damage the board and the I/O controller.
Table 2-1. Board connectors, cables, accessory equipment
50-pin, high-density IDC male header connector
C50FF-x (Figure 2-1)
SCB-50
CIO-MINI50
CIO-SPADE50
CIO-ERB24
CIO-SERB24/FD
CIO-ERB48
CIO-SERB48
SSR-RACK24
SSR-RACK48
ble 2-2
.
2-3
Installing the PCI-DIO48H
.
