Fig. 8 Polarity reversal input from FACP signaling circuit
output (polarity is referenced in alarm condition):
JUMPER J3
Fig. 9 Normally Open - Non-Latching FACP
trigger input:
Fig. 11 Normally Closed - Non-Latching FACP
trigger input:
- 14 -

FACP Hook-up Diagrams:

CUT
FACP
SIGNAL CIRCUIT
OUTPUT EOL
FROM FACP
--
SIGNAL OUTPUT
+
N.O. TRIGGER
INPUT
N.C. DRY
TRIGGER
INPUT
JUMPER
CIRCUIT
Fig. 10 Normally Open FACP Latching trigger input
with reset:
(This output has not been evaluated by UL)
Fig. 12 Normally Closed - Latching FACP trigger input
with reset:
(This output has not been evaluated by UL)
N.O.
TRIGGER
INPUT
JUMPER
N.C. RESET
JUMPER
Maximal3/Maximal5/Maximal7 Access Power Controllers (Fused)
N.C.
RESET
SWITCH
SWITCH
N.C. TRIGGER
INPUT
