1.25"
(31.75mm)
8.5"
(215.9mm)
7.5"
(190.5mm)
26"
(660.4mm)
LEFT
10"
(254mm)
Maximal3/Maximal5/Maximal7 Access Power Controllers (Fused)
Enclosure Dimensions (H x W x D approx.):
26" x 19" x 6.25" (660.4mm x 482.6mm x 158.75mm)
2"
4"
(50.8mm)
(101.6mm)
0.85"
8.9"
(21.59mm)
(226.06mm)
1.5"
(38.1mm)
26"
(660.4mm)
1"
(25.4mm)
0.85"
8.9"
(21.59mm)
(226.06mm)
19"
(482.6mm)
7"
4"
(177.8mm)
(101.6mm)
TOP
19"
(482.6mm)
8.4"
(213.36mm)
8.4"
(213.36mm)
BOTTOM
4"
(101.6mm)
19"
(482.6mm)
2"
(50.8mm)
6.25"
(158.75mm)
0.85"
(21.59mm)
1.5"
(38.1mm)
5"
(127mm)
7.5"
(190.5mm)
RIGHT
1"
(25.4mm)
0.85"
(21.59mm)
6.25"
(158.75mm)
2"
(50.8mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
1.25"
(31.75mm)
7"
(177.8mm)
8.5"
(215.9mm)
26"
(660.4mm)
7"
(177.8mm)
2"
(50.8mm)
1.25"
(31.75mm)
- 15 -
