Facp/Optional Power Supply Hook-Up Diagrams - Altronix Maximal3FD Installation Manual

Fig. 5 Polarity reversal input from FACP
signaling circuit output (polarity is
referenced in alarm condition):
CUT
JUMPER
FACP
TRG
Fig. 6 Normally Open: Non-Latching FACP
trigger input:
FACP
TRG
Fig. 8 Normally Closed: Non-Latching FACP
trigger input:
FACP
TRG
- 12 -
FACP Hook-Up Diagrams:
FACP
OUTPUT EOL
FROM FACP
--
OUTPUT
+
CIRCUIT
N.O. TRIGGER
INPUT
N.C. DRY
TRIGGER
INPUT
JUMPER
Fig. 7 Normally Open FACP Latching trigger
input with reset (This output has not been
evaluated by UL):
FACP
TRG
Fig. 9 Normally Closed: Latching FACP trigger
input with reset (This output has not been
evaluated by UL):
FACP
TRG
Maximal3FD/Maximal5FD/Maximal7FD Access Power Controllers (PTC)
N.O.
TRIGGER
INPUT
N.C. RESET
SWITCH
JUMPER
N.C. RESET
SWITCH
N.C. TRIGGER
JUMPER
INPUT
