Facp Hook-Up Diagrams - Altronix Maximal1RHV Installation Manual

Polarity Reversal Input from FACP Signal Circuit Output
Fig. 5
GND
IN8
1
FACP
2
RESET
Factory Installed
Jumper
GND
Non-Latching
Fig. 7
GND
IN8
1
Normally Closed [NC] Dry
FACP
2 Trigger Input
RESET
Factory Installed
Jumper
GND
Non-Latching
Fig. 9
GND
IN8
1
Normally Open [NO] Dry
FACP
2
Trigger Input
RESET
GND
Factory Installed
Jumper
Non-Latching
Maximal Rack Access Power Controllers (Fused)

FACP Hook-Up Diagrams

(Polarity is referenced in alarm condition)
5-30VDC
--
from FACP
+
Signal Circuit
Normally Closed Input from FACP
Normally Open Input from FACP
Fig. 6
GND
IN8
1
FACP
2
Normally Open [NO]
RESET
Reset Switch
GND
Fig. 8
GND
IN8
Normally Closed [NC] Dry
1
FACP
Trigger Input
2
Normally Open [NO]
RESET
Reset Switch
GND
Fig. 10
GND
IN8
1
FACP
2
RESET
GND
Normally Open [NO]
Reset Switch
5-30VDC
--
from FACP
+
Signal Circuit
Latching
Latching
Normally Open [NO]
Dry Trigger Input
Latching
- 9 -
