Altronix Maximal Series Installation Manual

Altronix Maximal Series Installation Manual

Dual power supply
Hide thumbs Also See for Maximal Series:

Advertisement

Quick Links

Download this manual
Maximal Series
Dual Power Supply
Access Power Controllers (fused)
Models Include:
Maximal11
- Power Supply 1:
12VDC @ 3.5A or 24VDC @ 2.7A.
- Power Supply 2:
12VDC @ 3.5A or 24VDC @ 2.7A.
- Sixteen (16) fuse protected
power-limited outputs.
Maximal33
- Power Supply 1:
12VDC @ 5.5A or 24VDC @ 5.7A.
- Power Supply 2:
12VDC @ 5.5A or 24VDC @ 5.7A.
- Sixteen (16) fuse protected
non power-limited outputs.
Installation Guide
Rev. MDF052219
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
Altronix Corp.
140 58th St. Brooklyn, NY
Maximal55
- Power Supply 1: 12VDC @ 9.5A.
- Power Supply 2: 12VDC @ 9.5A.
- Sixteen (16) fuse protected
non power-limited outputs.
Maximal75
- Power Supply 1: 12VDC @ 9.5A.
- Power Supply 2: 24VDC @ 9.7A.
- Sixteen (16) fuse protected
non power-limited outputs.
Maximal77
- Power Supply 1: 24VDC @ 9.7A.
- Power Supply 2: 24VDC @ 9.7A.
- Sixteen (16) fuse protected
non power-limited outputs.
More than just power.
TM

Advertisement

loading
Need help?

Need help?

Do you have a question about the Maximal Series and is the answer not in the manual?

Questions and answers

Related Manuals for Altronix Maximal Series

Summary of Contents for Altronix Maximal Series

  • Page 1 Maximal Series Dual Power Supply Access Power Controllers (fused) Models Include: Maximal11 Maximal55 - Power Supply 1: - Power Supply 1: 12VDC @ 9.5A. 12VDC @ 3.5A or 24VDC @ 2.7A. - Power Supply 2: 12VDC @ 9.5A. - Power Supply 2: - Sixteen (16) fuse protected 12VDC @ 3.5A or 24VDC @ 2.7A.

  • Page 2: Table Of Contents

    Maximal Series Configuration Chart ........

  • Page 3: Maximal Series Overview

    Electric Strikes, Magnetic Door Holders, etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs. All interconnecting equipment must be UL Listed. Maximal Series Configuration Chart: Altronix Agency Listings...

  • Page 4: Maximal Series Features

    Maximal Series Features: • Sixteen (16) independently trigger controlled outputs. Output options: a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs. b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs. c) Sixteen (16) form “C” relay outputs (rated @ 5A/28VDC or VAC).
  • Page 5 2. The power supply is pre-wired to the ground (chassis). Connect main incoming ground to the provided green grounding conductor lead. Connect unswitched AC power (115VAC, 60Hz) to the terminals marked [L, N] on both power supply boards. Green “AC” LED on power supply board will turn on. This light can be seen through the LED lens on the door of the enclosure.

  • Page 6: Maintenance

    12. Installation of tamper switch (Not Included) (Figs. 3a, 4a, 5a, pgs. 10-12): Mount UL Listed tamper switch (Altronix Model TS112 or equivalent) at the top of the enclosure. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side. Connect tamper switch wiring to the Access Control Panel input or the appropriate UL Listed reporting device.

  • Page 7: Power Supply Board Terminal Identification

    Power Supply Board Terminal Identification: Terminal Legend Function/Description L, G, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral. Maximal11 - 12VDC @ 3.5A or 24VDC @ 2.7A to ACM8 boards (power-limited). Maximal33 - 12VDC @ 5.5A or 24VDC @ 5.7A to ACM8 boards (non power-limited). Maximal55 - 12VDC @ 9.5A to ACM8 boards (non power-limited).

  • Page 8: Power Supply Board Led Diagnostics

    LED 1- LED 8 (Red) Output relay(s) energized. Output relay(s) de-energized. Trg (Green) FACP input triggered (alarm condition). FACP normal (non-alarm condition). Power Supply Board Stand-by Battery Specifications: Altronix 20 Min. of 24 Hr. of Power Supply Board Battery 4 Hr. of Backup...

  • Page 9: Power Supply Board Output Voltage Settings

    Power Supply Board Output Voltage Settings: Fig. 1a - Maximal11 and Maximal33 Power Supply Board OFF - 24V Fig. 1b ON - 12V OFF - 24V ON - 12V Access Power Controller Typical Application Diagram (for each ACM8): Fig. 2 Fig.

  • Page 10: Maximal11, Maximal33, Maximal55 Battery Hookup And Tamper Switch Installation

    Fig. 3 - Maximal11, Maximal33, Maximal55 Tamper Switch Power Supply Board BAT FAIL NC C NO NC C NO AC FAIL Line Neutral Earth Ground Power Supply Board BAT FAIL NC C NO NC C NO AC FAIL Line Neutral Input 115VAC 60Hz CAUTION: When power supply board is set for 12VDC use only one (1) 12VDC stand-by battery.

  • Page 11: Maximal75 Battery Hookup And Tamper Switch Installation

    Fig. 4 - Maximal75 Tamper Switch Power Supply Board BAT FAIL NC C NO NC C NO AC FAIL Line Neutral Earth Ground Power Supply Board BAT FAIL NC C NO NC C NO AC FAIL Line Neutral Input 115VAC 60Hz Optional 12VDC Optional 12VDC Rechargeable...

  • Page 12: Maximal77 Battery Hookup And Tamper Switch Installation

    Fig. 5 - Maximal77 Tamper Switch Power Supply Board BAT FAIL NC C NO NC C NO AC FAIL Line Neutral Earth Ground Power Supply Board BAT FAIL NC C NO NC C NO AC FAIL Line Neutral Input 1150VAC 60Hz Optional 12VDC Optional 12VDC Rechargeable...

  • Page 13: Nec Power-Limited Wiring Requirements For Maximal11

    NEC Power-Limited Wiring Requirements for Maximal11: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below.

  • Page 14: Nec Power-Limited Wiring Requirements For Maximal33 And Maximal55

    NEC Power-Limited Wiring Requirements for Maximal33 and Maximal55: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below.

  • Page 15: Nec Power-Limited Wiring Requirements For Maximal75

    NEC Power-Limited Wiring Requirements for Maximal75: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below.

  • Page 16: Nec Power-Limited Wiring Requirements For Maximal77

    NEC Power-Limited Wiring Requirements for Maximal77: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below.

  • Page 17: Facp/Optional Power Supply Hook-Up Diagrams

    FACP/Optional Power Supply Hook-up Diagrams: Fig. 10 Optional hook-up using two (2) isolated power supply inputs (Only applicable on Maximal11): CUT JUMPERS J1 AND J2 ISOLATED POWER INPUT 12 OR 24 VAC OR VDC (ACM8 POWER) ISOLATED POWER INPUT 12 OR 24 VAC OR VDC (LOCK POWER) Fig.
  • Page 18 FACP/Optional Power Supply Hook-up Diagrams (cont’d): Fig. 13 Normally Open FACP Latching trigger input with reset: FACP N.O. TRIGGER INPUT N.C. RESET SWITCH JUMPER Fig. 14 Normally Closed - Non-Latching FACP trigger input: FACP N.C. DRY TRIGGER INPUT JUMPER Fig. 15 Normally Closed - Latching FACP trigger input with reset: FACP N.C.
  • Page 19 Notes: Maximal11/33/55/75/77 (Fused) Series Installation Guide - 19 -...

  • Page 20: Enclosure Dimensions

    (21.6mm) 4” (101.6mm) 2” (50.8mm) 19” (482.6mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIMaximal11/33/55/75/77 Series...
