Polarity Reversal Input from FACP Signal Circuit Output

Fig. 6
GND
IN8
1
FACP
2
RESET
Factory Installed
Jumper
GND
Non-Latching
Fig. 8
GND
IN8
1
FACP
2
RESET
Factory Installed
Jumper
GND
Non-Latching
Fig. 10
GND
IN8
1
FACP
2
RESET
GND
Factory Installed
Jumper
Non-Latching
Maximal Rack Access Power Controllers (PTC)

FACP Hook-Up Diagrams

(Polarity is referenced in alarm condition)
5-30VDC
--
from FACP
+
Signal Circuit

Normally Closed Input from FACP

Normally Closed [NC]
Dry Trigger Input

Normally Open Input from FACP

Normally Open [NO] Dry
Trigger Input
Fig. 7
GND
IN8
1
FACP
2
RESET
GND
Fig. 9
GND
IN8
1
FACP
2
RESET
GND
Fig. 11
GND
IN8
1
FACP
2
RESET
GND
Normally Open [NO]
Reset Switch
5-30VDC
--
from FACP
+
Signal Circuit
Normally Open [NO]
Reset Switch
Latching
Normally Closed [NC]
Dry Trigger Input
Normally Open [NO]
Reset Switch
Latching
Normally Open [NO]
Dry Trigger Input
Latching
- 9 -
