• To raise or lower the Monitors minutely, use the Adjustment Screws located
on the top of the VESA Adapters. (Figure 27)
Figure 27
Adjustment
Screw
• To move the Monitors along the Monitor Arms, use a Phillips Head
Screwdriver to loosen the Screw located on the underside of each of the
VESA Adapters. Move the Monitors left or right on the Monitor Arms, and
tighten each of the Screws when the Monitors are in the desired locations.
(Figure 28)
Warning! Make sure that you loosen the Screw on the underside of the VESA
Adapters before you move them along the Monitor Arms. If you move the VESA
Adapters without loosening the Screws, you might damage the surface of the
Monitor Arms.
Figure 28
