StarTech.com ARMBARDUOG User Manual page 12

3. Screw the Column into the top of the Desk-Mount Clamp. (Figure 3)
4. Use the Hex Key Screwdriver to tighten the screws in the Desk-Mount Clamp.
(Figure 4)
Figure 3
5. Seat the Mounting Cover so that it is flush with the top of the Desk-Mount Clamp.
(Figure 5)
Figure 5
User Manual
Column
Desk Clamp
Figure 4
Column
Mounting Cover
Desk-Mount Clamp
8
Hex Key
Screwdriver
