Attach the Cable-Management Clips

1. Snap one of the Cable-Management Clips (Monitor Arm) over each of the two
Monitor Arms. (Figure 21)
Figure 21
Cable-Management
Clip (Column)
2. Snap the two Cable-Management Clips (Column) over the Column. (Figure 22)
Figure 22
3. Route the Monitor Cables through the Cable-Management Clips on the Monitor
Arms and through the Cable-Management Clips on the Column.
User Manual
Cable-Management
Clip (Monitor Arm)
Column
Cable-Management
Clips (Column)
