Use the Grommet Mount to Attach the ARMBARDUOG
Warning! Ensure that the weight of the Monitors does not exceed the weight capacity
of this product. If you exceed the weight capacity, you may experience personal
injury or damage to your Monitors and ARMBARDUOG. This product can support the
following weight capacities: Up to 8 kg (17.6 lb.) per monitor mount, for a total of 16 kg
(35.2 lb.).
1. Remove the Mounting Cover from the top of the Desk-Mount Clamp. (Figure 8)
Desk-Mount Mounting
Figure 8
Clamp Cover
2. Insert a Phillips Head Screwdriver through the top of the Desk-Mount Clamp and
unscrew the Screw. Remove the Washer, Screw, Plate, and Rod. (Figure 9)
Tip! Keep the Washer, Screw and Plate in a safe place so that you can use them again
if you want to switch back to the Desk-Mount Clamp.
Figure 9
Screwdriver
Desk-Mount
Clamp
Screw
Plate
Rod
